Pekos DIN floating ball valves provide reliable zero-leakage shut-off and low-emission performance, ensuring safe operation across a wide range of European process applications. Their durable carbon steel and stainless steel constructions, combined with versatile PTFE-based seat options, deliver long service life and excellent chemical compatibility. With anti-static protection, blow-out proof stems and self-relieving cavity design, they offer dependable isolation and reduced maintenance in demanding industrial environments.
Pekos
DIN Floating Ball Valve
Soft seated design with Zero seat leakage, low emission design as standard, with maintenance free packing.
Specifications
Size Range
DN15-DN300
Pressure Class
PN10-16-25-40-63-100
Materials
CS & SS 1.0619/1.6220/1.4408/1.4309
Trim
SS 1.4408
Construction
2-Piece bolted
Design
EN-12516, ISO 17292, EN 558, EN-12266, ISO 5208
Seat Inserts
Standard Seats PTFE, RPTFE & TFM, Multiple seat options available to suit application
Certification
DNV, Lloyd's register, TUV, TA-Luft,PED, BS 6364, ATEX, EN 161, SIL3, DVGW, API 6D
Features
Auto adjustable packing, Anti Blow out stem, Anti Static device, Self Cavity pressure relief, seating options to suit applications
Applications
Chemical, Petrochemical, Power, Water and general industrial process isolation
- DN15-DN300
- Fully European
- 2-Piece bolted
