Air Torque rack and pinion pneumatic actuators combine compact, modular design with fourth-generation engineering to deliver reliable and efficient valve automation. Their dual-piston construction provides consistent performance in both double-acting and spring-return configurations, while hard-anodised aluminium or stainless steel housings ensure durability in harsh environments. With ATEX, SIL3 and IP67/IP68 certification, flexible mounting options and advanced safety features, they offer dependable, low-maintenance actuation for demanding process and pipeline applications.
Air Torque
Rack & Pinion Pneumatic Actuators
Compact modular design, latest technological innovations in the 4th Generation series upgrade
Specifications
Size Range
17 different sizes, up to 10,000 Nm torque output, AT051U-AT1001U allows economic sizing selection
Pressure Class
2.5 Bar min / 8.0 Bar max
Materials
Extruded Aluminium, hard anodized, with several protection levels. (St.Steel option also available)
Construction
Dual piston Rack & Pinion, double acting and spring return
Design
ISO 5211, DIN 3337, VDI/VDE 3845
Certification
ATEX 2014/34/EU, DNV Type approval, SIL3, CE, IP67 & IP68 protection
Features
-40Deg c standard low temp, multiple choice of ISO flange and drive shaft connection, SS Fasteners, stroke adjustment, fast acting options, extra independent travel stop adjustment for opening and closing, lockout capability, multiple protection levels, wide range of working temperatures. Unique position indication, universal and anti-blowout drive shaft, no external cavities avoiding deposit build up. In-line and across line installation versatility
- Up to 10,000 Nm torque output,
- Fully European
- 8.0 Bar max
